Various types of solder line-up; Lead-free & Lead-contained
|
 |
Lead-free(Pb-free) solder (Tin · Silver · Copper) |
| |
· Environmentally-friendly "Lead-free" solder |
| |
· High melting point due to Lead-free |
| |
|
| |
|
| |
Lead-contained solder |
| |
· Containing lead makes melting point low, resulting in good solder fluidity. |
| |
· Owing to its high reliability, lead-contained solder prevails at air industry, space exploration and so on. |
| Lead-free |
Variety of Shape, Size and Volume |
 |
- Attaching roll solder to Solder Reel Stand HAKKO 611 increases its workability.
No.611-1 |
No.611-2 |
|
|
- Contains flux(resin).
- Main applications: For production line, repair section etc.
|
| Lead-contained |
 |
| Lead-free |
Variety of Shape, Size and Volume |
 |
- Suitable volume of soldering for hobby use etc.
- Contains flux(resin).
- Main applications: For repair of home appliance, assembly of plastic model or radio control model etc.
|
| Lead-free |
Lead-contained |
 |
 |
| Lead-contained |
Variety of Shape, Size and Volume |
 |
- Dimensions vary slightly.
- Flux-free(Resin-free)
*Please apply flux for sheet metal working, soldering pot etc.
- Main applications: For soldering pot, processing stainless material, sheet metal working, stained-grass etc.
|
| Lead-contained |
Variety of Shape, Size and Volume |
 |
- Attaching roll solder to Solder Reel Stand HAKKO 611 increases its workability.
No.611-1 |
No.611-2 |
|
|
- No flux contained
*Please apply flux for stainless material(HAKKO SUSSOL-F).
|
|
 Roll solder |
| Lead-free |
| PartNo. |
Type |
Component |
Melting point |
Weight |
Dimensions |
Applications |
| FS500-01 |
KIKKO |
Tin99%
Siliver0.3%
Cupper0.7% |
227°C |
500g |
ø0.6mm |
Solder for
Chip soldering,
Micro-soldering
|
Soldering for Transistor, Resistor, Diode, Capacitor, IC etc. on PWB |
| FS501-01 |
1kg |
ø0.8mm |
| FS501-02 |
ø1.0mm |
| FS501-03 |
ø1.2mm |
| FS600-01 |
150g |
ø0.6mm |
Solder for Chip soldering,
Micro-soldering
|
| FS600-02 |
ø0.8mm |
Solder for IC·PWB |
| FS600-03 |
ø1.0mm |
Solder for general electrical work |
| FS600-04 |
ø1.2mm |
Solder for R/C model·Audio instrument·general electrical wiring |
| Lead-contained |
| Part No. |
Type |
Component |
Melting point |
Weight |
Dimensions |
Applications |
| FS301-01 |
KIKKO |
Tin 30%
|
215°C |
1kg |
ø3.0mm |
Solder for Lead work |
| FS302-01 |
Tin 60% |
190°C |
1kg |
ø1.0mm |
Solder for general electrical work, big chips such as transformer etc. on PWB. |
| FS302-02 |
ø1.2mm |
| FS302-03 |
ø1.6mm |
| FS302-04 |
ø2.0mm |
| FS303-01 |
500g |
ø1.6mm |
| FS303-02 |
ø2.0mm |
| FS402-01 |
190°C |
150g |
ø0.6mm |
Solder for Chip soldering,
Micro-soldering
|
Soldering for Transistor, Resistor, Diode, Capacitor, IC etc. on PWB |
| FS402-02 |
ø0.8mm |
Solder for IC·PWB |
| FS402-03 |
ø1.0mm |
Solder for IC·PWB |
| FS402-04 |
ø1.6mm |
Solder for big chips such as transformer on PWB |
| FS403-01 |
Tin 50%
|
215°C |
150g |
ø1.2mm |
Solder for Plastic model work |
Joint for power strip, switch, connector, etc.
Work for R/C model, plastic model
|
| FS403-02 |
ø1.6mm |
Solder for learning materials in school, process & repair for copper/brass |
| Small-volume solder |
| Lead-free |
| Part No. |
Type |
Component |
Melting point |
Weight |
Dimensions |
Length
(Approx.) |
Applications |
| FS601-01 |
KIKKO |
Tin 99%,
Silver0.3%,
upper0.7% |
227°C |
10g |
ø0.6mm |
5.3m |
Solder for
Chip soldering, Micro-soldering |
Soldering for Transistor,
Resistor, Diode, Capacitor, IC etc. on PWB |
| FS601-02 |
ø0.8mm |
3.7m |
Solder for
IC· PWB |
| FS601-03 |
15g |
ø1.0mm |
3.3m |
Solder for
general electrical work |
| FS601-04 |
20g |
ø1.2mm |
2.8m |
Solder for R/Cmodel· Audio instrument · general electrical wiring |
| FS602-01 |
3g |
ø0.8mm |
1.5m |
Solder for IC· PWB |
| Lead-contained |
| Part No. |
Type |
Component |
Melting point |
Weight |
Dimensions |
Lengt
(Approx.) |
Applications |
| FS406-01 |
KIKKO |
Tin 50% |
215°C |
20g |
ø1.0mm |
3.0m |
Solder for Home appliance |
Joint for power
strip, switch, connector, etc.Work for R/C model, plastic model |
| FS406-02 |
ø1.2mm |
2.9m |
Solder for Plastic
Model |
| FS406-03 |
ø1.6mm |
1.5m |
Solder for process&
repair for copper⁄
brass |
| FS407-01 |
Tin 60% |
190°C |
20g |
ø0.8mm |
4.3m |
Solder for IC · PWB |
Solder for Chip soldering, Micro-soldering Soldering for Transistor, Resistor, Diode, Capacitor, IC etc.
on PWB
|
| FS407-02 |
ø1.0mm |
3.0m |
Solder for general electrical work |
| FS407-03 |
ø1.2mm |
2.9m |
Solder for R/Cmode· Audio instrument· general electrical wiring |
| FS407-04 |
ø1.6mm |
1.5m |
Solder for big chips such as transformer on PWB |
| FS408-01 |
183°C |
20g |
ø1.0mm |
3.2m |
For LSI· hybrid-IC Eutectic Solder
(Low Melting point:183°C)
Best for temp.
-sensitive soldering
such as MOS ⁄ IC ⁄ Flat I ⁄ Chips |
| FS409-01 |
Tin 62%, Silver 2%
|
190°C |
20g |
ø1.0mm |
3.2m |
Silver-contained solder for AV appliance |
| FS410-01 |
Tin 50% |
215°C |
10g |
Width Approx. 5mm |
0.5m |
Tape Solder It is for repair, twisting it
around the part for soldering, or holding it in between |
| FS411-01 |
6g |
ø1.6mm |
0.5m |
Solder for process & repair for copper ⁄ brass |
| Bar solder |
| Lead-contained |
| Part No. |
Type |
Component |
Melting point |
Style |
Weight |
Dimensions |
Applications |
| FS300-01 |
KAGOME |
Tin 30% |
258°C |
plate |
250g
× 4 |
325(L)×20(W)
×4(T)mm |
Without flux
For lead work
|
| FS400-01 |
KAGOME 0 |
Tin 60% |
190°C |
plate |
100g |
295(L)×13(W)
×3(T)mm |
Without flux
For Stainless material processing
For soldering pot
* Apply flux to joint-metal part for preparation
Micro-soldering, Tin work, Solder for Stainless material, Copper board, Yellow copper (Brass)
|
| FS400-02 |
round bar |
70g |
ø3×295(L)mm |
| FS401-01 |
KAGOME 1 |
Tin 50% |
215°C |
plate |
100g |
295(L)×13(W)
×3(T)mm |
| FS401-02 |
round bar |
70g |
ø3×295(L)mm |
| Solder for stainless materials |
| Lead-contained(Eutectic solder) |
| Part No. |
Type |
Component |
Melting point |
Dimensions |
Weight |
Length(Approx.) |
Applications |
| FS404-01 |
KIKKO |
Tin 60% |
190°C |
ø1.2mm |
150g |
- |
Without flux
Solder for stainless material, metal processing etc.
|
| FS404-02 |
500g |
| FS405-01 |
30g |
2.9m |
|
|
|
|
|
|
Roll solder(Wire solder)
